Mantall HT330 – 33m

Mantall HT330 telescopic boom lift has a working height of up to 33m, a maximum lifting capacity of 300kg, and is equipped with a large platform that can accommodate up to three workers and tools.

360-degree turntable rotation provides excellent flexibility for difficult work site applications. HT330 telescopic boom lift has a change mode of travel speed, which can adapt to various rough terrains.

Send forespørsel
Max. working height m

33m
Max. platform height m

31m
Max. outreach m

23m
Max. lift capacity kg

300kg
Platform size B*C*A

2.44*0.91*1.1m
Height-stowed D

3.05m
Length-stowed E

14.1m
Width F

2.49/3.95m
Wheelbase G

4.846/4.633m
Ground clearance H

0.33m
Turntable rotation

360°
Turntable tailswing

1.4m
Platform rotation

180°
Jib swing

–
Drive speed, stowed

4.2km/h
Drive speed, raised

1.1km/h
Gradeability (4WD)

40%
Min. turning radius-(inside)

4.08m
Min. turning radius-(outside)

6.89m
Drive wheels number

4
Steering Wheels number

4
Controls

Electro hydraulic proportional control
System voltage

DC 12V
Hydraulic tank capacity L

240L
Fuel tank capacity L

240L
Tire size

385/65-24
Power

Cummins engine QSF2.8T-C72 54kw
Max. tilt angle

3°
Vekt 20500 kg
Transportmål 1410 × 395 × 305 cm
Standard Features
  • Self-leveling platform
  • Hydraulic rotation platform
  • Hall effect fully proportional controls
  • Driving confirm
  • AC wiring to platform
  • 360° Turntable rotation
  • Horn
  • Hour meter
  • Tilt alarm
  • Positive traction drive
  • Dual Speed motor
  • Emergency pump
  • CAN intelligent control
  • Overload sensor
Optional
  • Platform swing gate
  • Platform alternate leverage
  • Welder connecting packages
  • Welder wire connecting to the platform
  • Airline to platform
  • Hydraulic oil cooler
  • Hostile environment packages
  • Anti-crash air packages
  • Tool tray
  • Alarm packages
  • Platform work lights
  • Traction packages
  • AC power source
  • Oscillating axle
