Mantall XE140RT – 14m

Mantall XE-RT series self-propelled rough terrain scissor lifts are a type of aerial work platform that uses battery power and operates without emission and noise.

The Mantall XE140RT has a maximum working height of 14 meters and a load capacity of 345 kg.

The lift has the characteristics of 30% gradeability, maximum traction speed of 4km/h, full-height driving, no emission and no noise. It is equipped with on-board diagnostic system, fault alarm device and strong power.

This lift has excellent driving force and climbing ability for rough terrain.

Send forespørsel
Working height max H1

14m
Platform height max H2

12m
Platform extension size

1.5 m
Lifting capacity

345 kg
Lifting capacity on the extension

136 kg
Dimension of the platform B*C*A

2.5*1.6*1.15 m
Platform length-extended K

4 m
Platform skirting board height L

0.15 m
Overall length and width E*F

2.67*1.76 m
Height stowed D

2.65 m
Height-guardrails folded M

1.98 m
Wheelbase G

1.89 m
Ground clearance H

0.17 m
Turning radius-inside

1.58 m
Turning radius-outside

3.89 m
Raising time/Lowering time

50/42s
Drive speed-stowed

4.0 km/h
Drive speed-raised

0.8 km/h
Gradeability

30%
Tilt Sensor (front to back/side to side)

3° / 2°
Outrigger level ability-front to back

9°
Outrigger level ability-side to side

13°
Hydraulic tank capacity

68 L
Tire size

675*280 mm
Max. platform occupancy (indoor/outdoor)

3/2 pers
Power source

48V 220Ah
Control

Control Proportional
Drive

2-wheels drive
Weight

4270 kg
Weight-with outriggers

4730 kg
Transportmål 267 × 176 × 265 cm
Standard Features
  • Foldable guardrail
  • Diagnostic system
  • AC wiring to platform
  • 2 wheel drive
  • Tilt level sensor with an audible alarm
  • Lowering alarm
  • Horn
  • Hour meter
  • Emergency pump
  • Proportional controls
  • Solid rough tire
  • Safety brackets
  • Dual flashing beacon
Optional
  • Automatic leveling hydraulic outriggers
  • Airline to platform
  • Overload sensor
  • Lithium battery
  • Non-mark rough tires

Function Description

  • Electric rough terrain scissor lift has zero emission and no noise characteristic. It also has strong climbing function.
  • Super load capacity, stable lifting, safe and reliable
  • 4 wheel drive with strong power and fast walking speed
  • With Diagnostic system, intelligent fault alarm system and other functions
