Mantall HT215J – 21.5m

Mantall HT215J telescopic boom lift has a working height of up to 21.5m and a maximum horizontal working range of 14.65m, and is equipped with a large platform that can accommodate three workers and tools.

HT215J is equipped with a jib and a 180-degree rotating platform, which provides better flexibility for various field applications. HT215J telescopic boom lift is driven by a diesel engine and has a variable speed operation mode, which can adapt to various rough terrains.

Send forespørsel
Max. working height m

21.5m
Max. platform height m

19.5m
Max. outreach m

14.65m
Max. lift capacity kg

230kg
Platform size B*C*A

1.8*0.76*1.1m
Height-stowed D

2.5m
Length-stowed E

10.6m
Width F

2.5m
Wheelbase G

2.8m
Ground clearance H

0.3m
Turntable rotation

360°
Turntable tailswing

1.2m
Platform rotation

180°
Jib swing

130°(+75°/-55°）
Drive speed, stowed

5.1km/h
Drive speed, raised

1km/h
Gradeability (4WD)

45%
Min. turning radius-(inside)

2.9m
Min. turning radius-(outside)

6.12m
Drive wheels number

4
Steering wheels number

2
Controls

Electro hydraulic proportional control
System voltage

DC 12V
Hydraulic tank capacity L

150L
Fuel tank capacity L

100L
Tire size

36*14-20; Rubber solid tires
Power

Cummins engine QSF2.8T3 43kw
Vekt 9510 kg
Transportmål 1060 × 250 × 250 cm
Standard Features
  • Self-leveling platform
  • Hydraulic rotation platform
  • Hall effect fully proportional controls
  • Driving confirm
  • AC wiring to platform
  • 360° Turntable rotation
  • Horn
  • Hour meter
  • Tilt alarm
  • Positive traction drive
  • Dual Speed motor
  • Emergency pump
  • CAN intelligent control
  • Overload sensor
  • Engine restart protection
  • Automatic engine failure shutdown
  • Spin out engine tray
Optional
  • Platform swing gate
  • Platform alternate leverage
  • Welder connecting packages
  • Welder wire connecting to the platform
  • Airline to platform
  • Hydraulic oil cooler
  • Hydraulic oil for extremely cold areas
  • Pipeline for extremely cold area
  • Hostile environment packages
  • Anti-crash air packages
  • Tool tray
  • Alarm packages
  • Platform work lights
  • Front driving light
  • Traction packages
  • AC power source
  • Preheater
  • Cold start components
  • AC generator set
  • Diesel exhaust gas purification muffler
  • Diesel fireproof star silencer
  • Air pre filter
